SISKIU DSE

SISKIU DSE

$ 1,300,00

EXCEED YOUR EXPECTATIONS

Unbelievably capable for any XC trails
Big thanks to modern geometry; a slacker head angle and longer reach and steeper seat, makes the Polygon Siskiu D series unbelievably capable for riders looking to tackle XC riding with some aggression. The anti-squat has been optimized for pedaling performance and the suspension is more progressive for when the trail gets rowdy. We improved support under power, enabling Siskiu D platform climbs like a hardtail without substituting comfort or traction. The downs are even better when you enjoy the climb up.
SKU: N/A Categories: , , ,

Description

*Specifications, colors, and product availability are subject to change without prior notice.
  • Frameset
    Frameset

    ALX XC TRAIL FRAME

    Fork

    SUNTOUR RAIDON32 BOOST LO-R

    Rear Shock

    ROCKSHOX DELUXE SELECT PLUS, E2E: METRIC 190x45mm, HARDWARE: M8x25mm FOR BOTH SIDES

    Size

    S, M, L, XL

    Frame Color

    CHARCOAL – WHITE

    Decal Color

    CRAYOLA BROWN – SILVER SAND

  • Drivetrain
    Shifter

    SHIMANO DEORE SL-M5100-R 11-SPEED TRIGGER

    Crank

    SHIMANO DEORE FC-M5100-1 32T TWO-PIECE-CRANK, CRANK ARM: 170mm (S-M) / 175mm (L-XL)

    Cassette

    SHIMANO DEORE CS-M5100 11-51T 11-SPEED

    Rear Derailleur

    SHIMANO DEORE RD-M5100-SGS DIRECT ATTACH 11-SPEED

    BB

    SHIMANO BSA THREADED 68/73mm

    Chain

    KMC X11-1

    Pedal

    ALLOY W/ ALLOY CAGE

  • Cockpit
    Saddle

    ENTITY SADDLE, STEEL ø 7mm

    Seatpost

    TRANZ X DROPPER 150mm / 170mm, DxL: 30.9 x 459mm (S-M) / 499mm (L-XL)

    Handlebar

    ENTITY EXPERT ALLOY, W: 780mm, BB: 31.8mm, R/D: 30mm, BEND: 6degree

    Handlestem

    ALLOY, EXT: 40mm, BB: 31.8mm, R/D: 7degree

    Headset

    THREADLESS TAPERED ZERO STACK, ZS 44/28.6 | ZS 56/40

  • Wheel & Tire
    Wheel Set

    X-15 TUBELESS READY W/ TUBELESS TAPE

    Tire

    PERFORMANCE TIRE 29″x2.25 (622-57)

    Rim

    ALLOY DOUBLE WALL 622-30 32H FOR TYRE 622-54/76

    Hub

    F: ALLOY THRU AXLE 15x110mm 32H CENTER LOCK / R: ALLOY THRU AXLE 12X148mm 32H CENTER LOCK

    Spokes

    STAINLESS J-BEND NDS:294mm DS:296mm W/ 14Gx12MM BRASS NIPPLE

  • Brake
    Brake Lever

    SHIMANO BL-MT201

    Brake Caliper

    SHIMANO MT201 HYDRAULIC DISC BRAKE

    Rotor

    SHIMANO SM-RT30 F:180mm R:160mm CENTER-LOCK

Geometry & Size

MM

  S M L XL
Height (cm) 155-165 165-175 175-185 185-195
Seat Tube Length (A) 395 435 487 522
Seat Tube Angle (B) 68.7 68.7 68.7 68.7
Effective Seat Tube Angle (C) 75.5 76 76 76
Head Tube Length (D) 90 102 112 122
Head Tube Angle (E) 67.5 67.5 67.5 67.5
Effective Top Tube (F) 579.5 603.9 624.3 646.7
Bb Height (G) 330 326 326 326
Bb Offset (H) 46 47 47 47
Chainstay Length (I) 435 436 436 436
Wheelbase (J) 1141.2 1165 1189 1213
Frame Reach (K) 425 445 465 485
Frame Stack (L) 597.4 606.7 615.9 625.2
Standover Height (M) 672 698 733 761

INCH

  S M L XL
Height (cm) 155-165 165-175 175-185 185-195
Seat Tube Length (A) 15.55 17.13 19.17 20.55
Seat Tube Angle (B) 2.7 2.7 2.7 2.7
Effective Seat Tube Angle (C) 2.97 2.99 2.99 2.99
Head Tube Length (D) 3.54 4.02 4.41 4.8
Head Tube Angle (E) 2.66 2.66 2.66 2.66
Effective Top Tube (F) 22.81 23.78 24.58 25.46
Bb Height (G) 12.99 12.83 12.83 12.83
Bb Offset (H) 1.81 1.85 1.85 1.85
Chainstay Length (I) 17.13 17.17 17.17 17.17
Wheelbase (J) 44.93 45.87 46.81 47.76
Frame Reach (K) 16.73 17.52 18.31 19.09
Frame Stack (L) 23.52 23.89 24.25 24.61
Standover Height (M) 26.46 27.48 28.86 29.96

Additional information

size

L, M, S, XL
color

Charcoal white
